1HP Solar Submersible Pump Package with 1200Wp Solar Panels and 0.75kW VFD
In Stock
Key Features
1HP Solar Submersible Pump: Designed for water pumping in agricultural and household applications.
1200Wp Tier-1 Solar Panels: Supports solar-powered water pumping with a specified 25-year panel performance warranty.
0.75kW VFD Inverter: Supports 150–450V DC input and 220V three-phase AC output, according to the supplied specifications.
Complete Installation Package: Includes solar panel structure, DCDB box, cables and fittings.
Multiple Water Supply Applications: Suitable for irrigation, household use, livestock, fish farming and remote locations.
Warranty and Service Support: Includes a specified 3-year pump and inverter warranty and 2-year home service support.
WhatsApp+880 1805 026888
Payment Option:
Payment options will be updated soon.
Product URL: https://www.muthobd.com/product/1-hp-solar-submersible-pump-package-with-1200-wp-solar-panels-and-0-75k-w-vfd
Specification
| Specification | Details |
|---|---|
| Product Name | 1HP Solar Submersible Pump Package |
| Brand | Rural Sun Power |
| Product Type | Solar Submersible Water Pump Package |
| Pump Capacity | 1HP |
| Delivery Size | 1.5-inch / 2-inch |
| Price in Bangladesh | ৳115,000 |
| Availability | Out of Stock |
| Applications | Irrigation, Household Water Supply, Livestock and Fish Farming |
| Specification | Details |
|---|---|
| Total Solar Capacity | 1.2kWp (1200Wp) |
| Panel Category | Tier-1 |
| Possible Panel Brands | Canadian Solar / JA Solar / LONGi / Trina |
| Performance Warranty | 25 Years |
| Specification | Details |
|---|---|
| Inverter Type | Variable Frequency Drive (VFD) |
| Rated Power | 0.75kW |
| Possible Brands | Micno / INVT / USFULL |
| DC Input Voltage Range | 150–450V |
| AC Output Voltage | 220V |
| AC Output Phase | 3-Phase |
| Specification | Details |
|---|---|
| Pump Type | Submersible Water Pump |
| Rated Power | 1HP |
| Delivery Size | 1.5-inch / 2-inch |
| Brand | Rural Sun Power |
| Standard | European Standard, as specified by the supplier |
| Warranty | 3 Years |
| Specification | Details |
|---|---|
| Solar Panel Structure | Included |
| Protection Box | DCDB |
| Cables | Included |
| Installation Fittings | Included |
| Transportation | Included, according to the supplier |
| Installation | Included, according to the supplier |
| Home Service Support | 2 Years |
| Component | Warranty |
|---|---|
| Solar Panels | 25 Years |
| Submersible Pump | 3 Years |
| VFD Inverter | 3 Years |
| Home Service Support | 2 Years |
Detailed description
1HP Solar Submersible Pump Package Price in Bangladesh
The 1HP Solar Submersible Pump Package is a complete solar-powered water pumping solution designed for agricultural, rural and household water supply applications in Bangladesh. Priced at ৳115,000, this package combines a 1HP Rural Sun Power submersible pump, 1200Wp Tier-1 solar panels and a 0.75kW Variable Frequency Drive (VFD) inverter.
The package also includes a solar panel mounting structure, DCDB protection box, cables, fittings, transportation and installation services. It is designed for customers seeking to reduce dependence on grid electricity and diesel-powered water pumping.
The product is currently listed as Out of Stock. Contact MuthoBD.com to confirm availability before placing an order.
1200Wp Tier-1 Solar Panel System
This solar water pumping package includes a total solar panel capacity of 1.2kWp (1200Wp). The listed panel brands include Canadian Solar, JA Solar, LONGi and Trina, depending on the supplied configuration.
Solar panels convert sunlight into electrical energy for the pumping system. This can help reduce recurring electricity or fuel expenses when the system is correctly sized and operated under suitable sunlight conditions.
The supplier specifies a 25-year solar panel performance warranty. Actual pumping performance depends on sunlight, panel orientation, installation conditions, water level and the required pumping head.
1HP Submersible Pump with VFD Inverter
The package includes a 1HP Rural Sun Power submersible pump with a 1.5-inch or 2-inch delivery connection. Submersible pumps operate below the water surface and are commonly used for groundwater extraction and other water supply requirements where the installation conditions are suitable.
A 0.75kW VFD inverter is included, with Micno, INVT and USFULL listed as possible brands. The specified DC input voltage range is 150–450V, with a 220V three-phase AC output. Confirm compatibility between the selected VFD and pump before installation.
For the correct pump selection, customers should check the borewell or water source depth, required water flow, total pumping head and intended daily water consumption. These factors determine whether a 1HP system will meet the site's requirements.
Complete Solar Pump Package with Installation
The package is supplied with the solar panel structure, DCDB box, cables and installation fittings. According to the supplier, transportation and full installation are included.
Having the main components supplied together can simplify system planning for farms, rural homes and small businesses. Before installation, confirm the structure design, cable lengths, electrical protection arrangements and any additional site preparation requirements.
Applications of the 1HP Solar Submersible Pump
This solar pumping system may be suitable for several applications in Bangladesh:
Agricultural irrigation: Pumping water for vegetables, crops, fruit cultivation and small agricultural plots.
Household water supply: Supporting domestic water pumping when the source and required pumping head are compatible.
Livestock farms: Providing water for cattle, poultry and other livestock.
Fish farming: Supporting suitable water transfer and pond-related applications.
Remote locations: Providing an alternative to conventional electricity-dependent pumping where grid access is limited.
Water output will vary according to the water source, installation depth, solar conditions and system configuration.
Warranty and After-Sales Support
The supplier specifies a 25-year solar panel performance warranty, a 3-year warranty for the pump and VFD inverter, and 2 years of home service support. Customers should verify the written warranty conditions, service coverage and exclusions before purchase.
Buy a Solar Submersible Pump Package from MuthoBD.com
The 1HP Solar Submersible Pump Package is designed for customers seeking a bundled solar water pumping solution with panels, inverter, pump and installation accessories. The listed price is ৳115,000, although the product is currently out of stock.
Contact MuthoBD.com for updated stock information, the exact component brands, installation details and confirmation that the package meets your water pumping requirements.
- The listed price is ৳115,000. The product is currently marked out of stock, so contact MuthoBD.com to confirm current availability and pricing.
