Crown Micro VOLTMORE-VMGI-3KW 3kW Three Phase On-Grid Solar Inverter

Crown Micro VOLTMORE-VMGI-3KW 3kW Three Phase On-Grid Solar Inverter

The Crown Micro VOLTMORE-VMGI-3KW Three Phase On-Grid Solar Inverter is designed for compatible three-phase grid-connected solar power installations. It combines MPPT solar technology, high stated conversion efficiency, a wide MPPT voltage range, IP66 enclosure protection, natural cooling, and optional smart monitoring.

For customers in Bangladesh planning a suitable residential, commercial, or business solar installation, this inverter is an option to consider when its electrical ratings match the solar array and three-phase grid connection requirements.

3kW Three-Phase Solar Power Conversion

The Crown Micro VOLTMORE-VMGI-3KW belongs to the 3kW power class and is specified as a three-phase on-grid solar inverter. An on-grid inverter converts the DC electricity generated by solar panels into AC electricity for a compatible grid-connected system.

Actual solar generation depends on the installed panel capacity, sunlight conditions, shading, panel orientation, temperature, and installation quality. Before selecting panels, verify the inverter's maximum PV input power, maximum DC voltage, and input current limits.

MPPT Technology with a Wide Voltage Range

This inverter uses Maximum Power Point Tracking (MPPT) technology to track the solar panels' optimal operating point as sunlight and operating conditions change.

The supplied specifications state an MPPT voltage range of 140V–1000V DC. This wide range can provide flexibility when designing a compatible solar panel string. However, the maximum DC input voltage and other electrical limits must be checked separately. The MPPT operating range should not be treated as confirmation of the maximum permissible DC voltage.

A qualified installer should calculate the panel string voltage under expected temperature conditions and confirm that the complete solar array complies with the manufacturer's requirements.

High Conversion Efficiency

The VOLTMORE-VMGI-3KW has a stated maximum efficiency of 98.6% and European efficiency of 97.9%. These figures describe the inverter's rated conversion performance under specified test conditions.

Actual efficiency depends on operating load, temperature, solar input, and grid conditions. The maximum efficiency figure should not be interpreted as a guarantee of continuous performance at that level.

Three-Phase Grid-Connected Operation

This model is designed for compatible three-phase grid-connected solar installations. Before installation, ensure that the inverter's rated AC voltage, frequency, current, and grid-protection requirements match the electricity supply and applicable utility requirements.

As an on-grid inverter, it should not be assumed to provide backup electricity during a grid outage unless a supported backup function is explicitly confirmed. Customers who require power during load shedding should verify the availability of a compatible backup solution.

SREDA Approval and Net Metering

The Crown Micro VOLTMORE-VMGI-3KW is listed as SREDA approved for the net metering program. Net metering may allow eligible consumers to export surplus solar electricity to the utility grid under applicable regulations and electricity distribution company requirements.

Before purchasing, verify the current approval status of this exact model and confirm the requirements of the relevant utility.

IP66 Protection and Natural Cooling

The inverter features an IP66-rated enclosure, designed to protect against dust ingress and powerful water jets under specified test conditions. Its natural cooling system uses airflow and heat dissipation rather than relying on forced-air cooling.

For reliable operation, install the inverter according to the manufacturer's instructions, including appropriate mounting, clearance, temperature, and environmental requirements.

Wi-Fi and 4G Smart Monitoring

Optional Wi-Fi and 4G monitoring allow compatible communication accessories to be used for supported remote monitoring. Confirm whether the required monitoring device is included in the package and check the connectivity requirements before purchase.

10-Year Warranty

The Crown Micro VOLTMORE-VMGI-3KW is listed with a 10-year warranty. Buyers should confirm the coverage, exclusions, registration requirements, and after-sales service arrangements with the seller.

Buy Crown Micro VOLTMORE-VMGI-3KW from MuthoBD.com

If you are looking for a Crown Micro 3kW three-phase on-grid solar inverter in Bangladesh, the VOLTMORE-VMGI-3KW is an option to evaluate for a compatible grid-connected solar installation. Its stated efficiency, wide MPPT range, IP66 protection, natural cooling, and optional smart monitoring make it worth considering for suitable projects.

Explore solar inverters and related solar power products at MuthoBD.com. Always verify the official datasheet and grid compatibility before ordering.
