Deye SUN-8K-SG05LP1-EU-SM2 8kW Single Phase Hybrid Solar Inverter
In Stock
Key Features
8kW Single-Phase Hybrid Inverter: Designed for compatible residential and commercial solar installations.
10,400W Maximum DC Input Power: Supports a substantial solar panel array within the specified electrical limits.
Dual MPPT Technology: Helps optimize solar energy harvesting.
48V Battery Compatibility: Supports compatible lead-acid and lithium-ion batteries.
190A Maximum Battery Charging/Discharging Current: Supports high-current battery energy transfer.
Colourful Touch LCD: Provides a convenient interface for monitoring and configuring supported functions.
Parallel Operation up to 16 Units: Allows system expansion in compatible configurations.
AC Coupling Support: Enables integration with compatible existing solar installations.
Wi-Fi Monitoring Options: Supports remote monitoring through a compatible communication setup.
IP65 Protection: Provides dust protection and resistance to water jets under specified test conditions.
Intelligent Air Cooling: Helps manage operating temperature.
5-Year Official Warranty: As supplied; confirm the applicable warranty terms.
WhatsApp+880 1805 026888
Payment Option:
Payment options will be updated soon.
Product URL: https://www.muthobd.com/product/deye-sun-8-k-sg05-lp1-eu-sm2-8k-w-single-phase-hybrid-solar-inverter
Specification
| Specification | Details |
|---|---|
| Brand | Deye |
| Model | SUN-8K-SG05LP1-EU-SM2 |
| Product Type | Single-Phase Hybrid Solar Inverter |
| Rated AC Output Power | 8,000W / 8kW |
| Maximum AC Output Power | 8,800W |
| Battery System | 48V Low-Voltage Battery |
| Battery Voltage Range | 40–60V |
| Display | Colourful Touch LCD |
| Monitoring | Wi-Fi / Compatible Monitoring Options |
| Enclosure Protection | IP65 |
| Cooling System | Intelligent Air Cooling |
| Installation Type | Wall-Mounted |
| Parallel Operation | Up to 16 Units |
| AC Coupling | Supported |
| Warranty | 5-Year Official Warranty, as supplied |
| Specification | Details |
|---|---|
| Battery Types | Lead-Acid / Lithium-Ion |
| Maximum Charging Current | 190A |
| Maximum Discharging Current | 190A |
| Charging Curve | 3-Stage / Equalization |
| Lithium Battery Charging Strategy | Self-adaptation to compatible BMS |
| External Temperature Sensor | Supported |
| Battery Communication | CAN / RS485 |
| Programmable Charging/Discharging | 6 Time Periods |
| Specification | Details |
|---|---|
| Maximum DC Input Power | 10,400W |
| Rated PV Input Voltage | 370V DC |
| Maximum PV Input Voltage | 500V DC |
| Start-Up Voltage | 125V DC |
| MPPT Voltage Range | 150–425V DC |
| Full-Load DC Voltage Range | 200–425V DC |
| Number of MPPT Trackers | 2 |
| Number of PV Strings | 2 MPPTs; 2 strings per MPPT on this model |
| Maximum Operating PV Input Current | 26A + 26A |
| Maximum PV Short-Circuit Current | 34A + 34A |
| MPPT Efficiency | Greater than 99% |
| Specification | Details |
|---|---|
| Rated AC Active Power | 8,000W |
| Maximum AC Active Power | 8,800W |
| Rated AC Input/Output Voltage | 220V / 230V |
| Phase | Single Phase |
| Grid Connection | L + N + PE |
| Rated Grid Frequency | 50Hz / 60Hz |
| 50Hz Frequency Range | 45–55Hz |
| 60Hz Frequency Range | 55–65Hz |
| Rated AC Input Current | 36.4A |
| Rated AC Output Current | 34.8A |
| Maximum AC Input Current | 40A |
| Maximum AC Output Current | 38.3A |
| Maximum Continuous AC Pass-Through | 50A |
| Off-Grid Peak Power | 2 × Rated Power for 10 Seconds |
| Power Factor Adjustment Range | 0.8 Leading to 0.8 Lagging |
| Total Current Harmonic Distortion | Less than 3% at nominal power |
| DC Current Injection | Less than 0.5% of rated current |
| Specification | Details |
|---|---|
| Single-Phase Output | Supported |
| Parallel Operation | Up to 16 Units |
| On-Grid Parallel Operation | Supported |
| Off-Grid Parallel Operation | Supported |
| AC Coupling | Supported |
| Multiple Battery Parallel Connection | Supported |
| Diesel Generator Integration | Supported for compatible configurations |
| Battery Scheduling | 6 Programmable Time Periods |
| Smart Energy Management | Supported |
| Specification | Details |
|---|---|
| Maximum Efficiency | 97.6% |
| European Efficiency | 96.5% |
| MPPT Efficiency | Greater than 99% |
| Specification | Details |
|---|---|
| PV Reverse Polarity Protection | Integrated |
| AC Output Overcurrent Protection | Integrated |
| AC Output Overvoltage Protection | Integrated |
| AC Output Short-Circuit Protection | Integrated |
| Thermal Protection | Integrated |
| Anti-Islanding Protection | Integrated |
| Insulation Impedance Detection | Integrated |
| Residual Current Detection | Integrated |
| DC Component Monitoring | Integrated |
| DC Surge Protection | Type II |
| AC Surge Protection | Type II |
| Arc Fault Circuit Interrupter | Optional, depending on configuration |
| Enclosure Protection | IP65 |
| Specification | Details |
|---|---|
| Communication Interfaces | RS485 / RS232 / CAN |
| Wi-Fi Monitoring | Verify included module for the supplied unit |
| Optional Monitoring | GPRS / Wi-Fi / Bluetooth / 4G / LAN, depending on accessories |
| Battery BMS Communication | Supported for compatible lithium batteries |
| Remote Monitoring | Supported with compatible communication equipment |
| Specification | Details |
|---|---|
| Operating Temperature | -40°C to +60°C |
| Temperature Derating | Above 45°C |
| Permissible Ambient Humidity | 0–100% |
| Maximum Installation Altitude | 2,000m |
| Noise Level | Less than 45dB |
| Enclosure Rating | IP65 |
| Cooling | Intelligent Air Cooling |
| Dimensions | 366 × 589.5 × 237mm, excluding connectors and brackets |
| Weight | Approximately 26.8kg |
| Installation | Wall-Mounted |
Detailed description
Deye SUN-8K-SG05LP1-EU-SM2 8kW Single-Phase Hybrid Solar Inverter
The Deye SUN-8K-SG05LP1-EU-SM2 8kW Hybrid Solar Inverter is designed for solar power systems that combine solar PV generation, battery storage and grid power. With an 8kW rated output and a 48V low-voltage battery system, it is suitable for consideration in compatible homes, offices and small commercial installations.
Available at MuthoBD.com, this Deye inverter combines dual MPPT technology, high-current battery charging and discharging, a colourful touch LCD, AC coupling and parallel operation.
8kW Single-Phase Power Output
The inverter provides 8,000W rated AC active power and up to 8,800W maximum AC active power according to the referenced specifications. It is designed to power compatible loads within its output and surge limits.
Before installation, calculate the total connected load and consider starting currents from refrigerators, pumps, motors and other appliances. Actual backup performance depends on battery capacity, solar generation, load demand and operating mode.
Solar Power Generation with Dual MPPT
The SUN-8K-SG05LP1-EU-SM2 supports up to 10,400W maximum DC input power. Its two MPPT trackers help optimize solar energy generation from compatible PV strings.
The maximum PV input voltage is 500V DC, while the MPPT operating range is 150–425V DC. Solar panels must be configured within the manufacturer's voltage and current limits. Correct string design is important for safe operation and efficient solar generation.
48V Battery Support and High-Current Charging
This hybrid inverter supports a 48V low-voltage battery system, with a specified battery voltage range of 40–60V. The official datasheet lists a maximum charging and discharging current of 190A for this model.
It supports compatible lead-acid and lithium-ion batteries. For lithium batteries, confirm BMS communication compatibility, battery current limits and manufacturer requirements before connecting the system.
Select battery capacity according to the required backup duration and the appliances that need to operate during a power outage.
Colourful Touch LCD Display
The colourful touch LCD provides a local interface for viewing supported system information and configuring available settings. It can help users and installers access operating information without relying solely on remote monitoring.
Available display functions depend on the device's firmware and configuration.
Parallel Operation for System Expansion
The product series supports parallel operation for up to 16 units in compatible configurations. This feature can provide flexibility when expanding an installation to meet higher power requirements.
Parallel systems require correct wiring, protection devices and manufacturer-approved configuration. The final system capacity depends on the supported operating mode and installation design.
AC Coupling and Energy Management
AC coupling support allows the inverter to be used in compatible system designs that integrate AC-connected solar equipment. This can be useful when upgrading or expanding an existing solar installation.
The series also supports programmable battery charging and discharging periods. Confirm the supported system arrangement and required equipment before installation.
Remote Monitoring and IP65 Protection
The SUN-8K-SG05LP1-EU-SM2 supports compatible remote monitoring options. Verify whether Wi-Fi monitoring is built into the specific unit or requires a separate communication accessory.
Its IP65-rated enclosure offers dust protection and resistance to water jets under specified testing conditions. IP65 does not mean the inverter can be submerged in water or exposed to every environmental condition without protection. Follow the manufacturer's installation and ventilation guidelines.
Why Choose the Deye SUN-8K-SG05LP1-EU-SM2 from MuthoBD.com?
The Deye SUN-8K-SG05LP1-EU-SM2 combines 8kW single-phase output, 48V battery compatibility, dual MPPT, high-current battery charging and discharging, parallel expansion and AC coupling support.
MuthoBD.com offers solar inverters, batteries and related power-system equipment for customers in Bangladesh. Before purchasing, confirm the exact model, battery compatibility, PV panel configuration, monitoring accessories and warranty terms with the seller or a qualified solar installer.
- The model number is SUN-8K-SG05LP1-EU-SM2.
