GoodWe GW5000-ES-C10 5KW Single Phase 48V Hybrid Solar Inverter
In Stock
Key Features
5KW single-phase hybrid inverter for residential energy storage systems.
Supports 48V Lithium-ion and Lead-acid batteries.
Dual MPPT design improves energy harvest from multiple solar arrays.
Supports up to 10KW PV input, allowing 200% DC oversizing.
97.6% maximum efficiency with 99.9% MPPT efficiency.
Built-in WiFi, LAN, Bluetooth, and RS485 for intelligent remote monitoring.
Smart fan cooling ensures reliable operation under heavy loads.
IP66-rated enclosure for indoor and outdoor installation.
Comprehensive protection including AFCI, anti-islanding, surge protection, and rapid shutdown support.
Compatible with the GoodWe monitoring platform for real-time energy management.
WhatsApp+880 1805 026888
Payment Option:
Payment options will be updated soon.
Product URL: https://www.muthobd.com/product/good-we-gw5000-es-c10-5-kw-single-phase-48-v-hybrid-solar-inverter
Specification
| Brand | GoodWe |
|---|---|
| Model | GW5000-ES-C10 |
| Product Type | Hybrid Solar Inverter |
| Inverter Type | Single Phase Hybrid (On-Grid + Battery Backup) |
| Application | Residential Solar Power System |
| Rated Output Power | 5000W (5KW) |
| Maximum Output Power | 5500W |
| Battery Voltage | 48V DC |
| Compatible Battery | Lithium-Ion / Lead-acid |
| Topology | Non-Isolated |
| Installation | Wall Mounted |
| Warranty | 5 Years* |
| Battery Type | Lithium-Ion / Lead-acid |
|---|---|
| Battery Voltage Range | 40V–60V |
| Number of Battery Inputs | 1 |
| Maximum Continuous Charging Current | 120A |
| Maximum Continuous Discharging Current | 120A |
| Maximum Charging Power | 5.0kW |
| Maximum Discharging Power | 5.5kW |
| Maximum PV Input Power | 10.0kW |
|---|---|
| Maximum PV Input Voltage | 600V |
| MPPT Operating Voltage Range | 60V–550V |
| Start-up Voltage | 58V |
| Nominal PV Voltage | 360V |
| Number of MPPT Trackers | 2 |
| Strings per MPPT | 1 |
| Maximum Input Current per MPPT | 20A |
| Maximum Short Circuit Current per MPPT | 26A |
| Rated Output Power | 5000W |
|---|---|
| Rated Apparent Power | 5.0kVA |
| Maximum Active Power | 5.5kW |
| Maximum Apparent Power | 5.5kVA |
| Output Voltage | 220V / 230V / 240V |
| Grid Frequency | 50Hz / 60Hz |
| Maximum AC Output Current | 25A |
| Rated Backup Power | 5.0kVA |
|---|---|
| Maximum Backup Power | 5.5kVA |
| Output Voltage | 220V / 230V / 240V |
| Output Frequency | 50Hz / 60Hz |
| Maximum Efficiency | 97.6% |
|---|---|
| European Efficiency | 96.2% |
| MPPT Efficiency | 99.9% |
| Battery to AC Efficiency | 95.5% |
| PV String Current Monitoring | Integrated |
|---|---|
| PV Insulation Resistance Detection | Integrated |
| Residual Current Monitoring | Integrated |
| PV Reverse Polarity Protection | Integrated |
| Battery Reverse Polarity Protection | Integrated |
| Anti-Islanding Protection | Integrated |
| AC Overcurrent Protection | Integrated |
| AC Short Circuit Protection | Integrated |
| AC Overvoltage Protection | Integrated |
| DC Switch | Integrated |
| Remote Shutdown | Integrated |
| DC Surge Protection | Type III |
| AC Surge Protection | Type III |
| AFCI | Integrated |
| Rapid Shutdown | Optional |
| Cooling Method | Smart Fan Cooling |
|---|---|
| Dimensions (W × H × D) | 560 × 444.5 × 226 mm |
| Weight | 29 kg |
| Operating Temperature | -35°C to +60°C |
|---|---|
| Relative Humidity | 0–95% |
| Maximum Operating Altitude | 3000 m |
| Protection Rating | IP66 |
| User Interface | LCD, WLAN + APP |
|---|---|
| Communication | RS485, WiFi + LAN + Bluetooth |
| BMS Communication | CAN |
| Communication Protocol | Modbus RTU / Modbus TCP |
Detailed description
The GoodWe GW5000-ES-C10 5KW Single Phase 48V Hybrid Solar Inverter is part of GoodWe's latest ES-C10 residential energy storage series, engineered to provide efficient solar power generation, intelligent battery management, and uninterrupted backup power for homes.
Designed around a 48V low-voltage battery system, this inverter supports both Lithium-Ion and Lead-acid batteries, giving homeowners the flexibility to build reliable and expandable solar energy storage systems. With support for 10KW maximum PV input, the GW5000-ES-C10 allows significant DC oversizing, enabling higher energy production throughout the day.
Its dual MPPT architecture independently tracks two solar arrays, maximizing energy harvest even when panels face different directions or experience partial shading. Combined with 97.6% maximum conversion efficiency and 99.9% MPPT efficiency, the inverter ensures excellent overall system performance.
Integrated WiFi, Bluetooth, LAN, and RS485 communication allow users to monitor solar generation, battery status, electricity consumption, and inverter performance through the GoodWe mobile application or web portal. The IP66-rated enclosure, smart fan cooling, and comprehensive protection features make the inverter suitable for Bangladesh's climate and demanding residential applications.
Key Features
Dual MPPT Technology
Two independent MPPT trackers maximize energy production from multiple roof orientations while reducing losses caused by shading.
Powerful Solar Input
Supports up to 10KW PV input, allowing oversized solar arrays that increase daily energy production without compromising system reliability.
Intelligent Hybrid Operation
Automatically manages energy flow between solar panels, batteries, household loads, and the utility grid for maximum self-consumption and dependable backup power.
Flexible Battery Compatibility
Compatible with 48V Lithium-Ion and Lead-acid batteries, making it suitable for a wide variety of residential battery storage solutions.
Smart Monitoring
Integrated WiFi, Bluetooth, LAN, and RS485 communication provide convenient real-time monitoring, firmware updates, and remote diagnostics through the GoodWe monitoring platform.
Reliable Protection
Comprehensive protection includes anti-islanding, PV reverse polarity protection, residual current monitoring, surge protection, AFCI, remote shutdown, and integrated DC switch for safe operation.
Technical Highlights
5KW single-phase hybrid inverter
48V battery platform
Supports Lithium-Ion & Lead-acid batteries
10KW PV input capacity
Dual MPPT design
600V maximum PV voltage
97.6% maximum efficiency
99.9% MPPT efficiency
WiFi + LAN + Bluetooth
LCD display
CAN BMS communication
Smart fan cooling
IP66 weatherproof enclosure
Wall-mounted installation
Applications
Ideal for:
Residential homes
Villas
Apartments
Small offices
Retail shops
Hybrid solar systems
Home battery storage
Backup power systems
Areas with frequent load shedding
Energy self-consumption systems
Why Choose This Product
The GoodWe GW5000-ES-C10 combines advanced hybrid technology, dual MPPT performance, intelligent battery management, and powerful solar input capacity in a compact design. It helps homeowners reduce electricity costs, improve energy independence, and maintain uninterrupted power during grid outages.
Its high efficiency, advanced communication capabilities, robust protection features, and durable IP66 enclosure make it an excellent long-term investment for residential solar installations.
Why Buy from MuthoBD
Purchase the GoodWe GW5000-ES-C10 from MuthoBD.com and enjoy:
100% Original GoodWe Products
Best Price in Bangladesh
Fast Nationwide Delivery
Secure Online Shopping
Professional Technical Consultation
Genuine Manufacturer Warranty
Reliable After-Sales Support
Expert Solar System Design Assistance
- The GoodWe GW5000-ES-C10 is a 5KW single-phase 48V hybrid solar inverter designed for residential solar energy storage systems. It combines solar generation, battery storage, and grid power management in one intelligent unit.
