LVTOPSUN LVTS-6KW-HYD 6kW 48V Solar Off-Grid Hybrid Inverter – 7800W PV Input, 2 Years Warranty

LVTOPSUN LVTS-6KW-HYD 6kW 48V Solar Off-Grid Hybrid Inverter

The LVTOPSUN LVTS-6KW-HYD 6kW Solar Off-Grid Hybrid Inverter is designed for compatible solar power and backup power installations. With 6000W pure sine wave output, a 48V battery system, and up to 7800W of solar PV input, it offers a range of features for residential and commercial off-grid applications.

6000W Pure Sine Wave Output

The LVTOPSUN LVTS-6KW-HYD provides a rated output power of 6000W (6kW) with pure sine wave output. It can power compatible electrical appliances within the inverter's operating limits.

When selecting an inverter, calculate the combined running wattage of connected appliances and account for the starting surge of equipment such as refrigerators, water pumps, and motors. Keep the total load within the rated output and applicable surge limits.

Up to 7800W Solar PV Input

This model supports up to 7800W of solar PV input and has an MPPT voltage range of 90V–500V. The MPPT function helps the solar charging system operate within the supported voltage range.

When designing the solar array, verify the panels' operating voltage, total open-circuit voltage, and current against the inverter's specifications. The solar panel configuration must remain within the manufacturer's permitted input limits.

48V Battery Compatibility

The LVTOPSUN LVTS-6KW-HYD is designed for a 48V battery system and supports lithium-ion and lead-acid batteries.

Before connecting a battery, check its nominal voltage, charging requirements, allowable current, and compatibility with the inverter's settings. Use appropriately rated cables, circuit protection, and installation equipment.

Fast 10ms UPS Transfer Time

With a specified UPS transfer time of 10 milliseconds, the inverter can switch connected loads to backup power quickly when the normal power source is interrupted. Actual performance may vary depending on operating mode and connected equipment.

Parallel Expansion up to 9 Units

The LVTOPSUN LVTS-6KW-HYD supports parallel expansion of up to nine units according to the supplied specifications. This feature can help system designers plan for higher combined capacity where supported.

Parallel installation requires compatible equipment, correct configuration, and compliance with the manufacturer's instructions. Confirm the supported parallel modes and installation requirements before connecting multiple inverters.

Suitable Applications

Depending on the battery capacity, solar panel configuration, and connected loads, this inverter may be considered for:

• Residential off-grid solar systems

• Home backup power installations

• Small commercial solar systems

• Offices and compatible backup power applications

• Larger installations requiring parallel inverter operation

The actual suitability depends on the required load, backup duration, battery performance, and installation design.

2-Year Warranty

The LVTOPSUN LVTS-6KW-HYD comes with a 2-year warranty, according to the supplied product information. Confirm the warranty terms, coverage conditions, and service process before purchasing.

Why Choose the LVTOPSUN LVTS-6KW-HYD?

With 6000W pure sine wave output, up to 7800W PV input, 48V battery support, 10ms UPS transfer time, and parallel expansion up to nine units, the LVTOPSUN LVTS-6KW-HYD is an option for compatible off-grid solar installations.

For customers in Bangladesh, selecting the right solar array and battery capacity is essential to meet daily energy consumption and backup requirements. Have the system designed and installed by a qualified technician to ensure compatibility and electrical safety.
