Secure Saral Single Phase Net Meter Price in Bangladesh
In Stock
Key Features
✅ Single-phase 2-wire direct-connected net meter
✅ Bidirectional import & export energy measurement
✅ Class 1.0 metering accuracy
✅ Up to 10kV surge withstand capability
✅ Multiple current options: 5–30A, 10–60A & 10–100A
✅ IEC 62056-21 optical communication with optional BLE/RS232 Micro-USB
WhatsApp+880 1805 026888
Payment Option:
Payment options will be updated soon.
Product URL: https://www.muthobd.com/product/secure-saral-single-phase-net-meter-price-in-bangladesh
Specification
| Specification | Details |
|---|---|
| Brand | Secure |
| Model | Saral |
| Product Type | Single Phase Energy / Net Meter |
| Connection | Direct Connected |
| Wiring | Single Phase, 2-Wire |
| Nominal Voltage | 230V / 240V |
| Frequency | 50Hz / 60Hz |
| Warranty | 1 Year Replacement Warranty |
| Specification | Details |
|---|---|
| Current Ratings | 5–30A, 10–60A, 10–100A |
| Accuracy Class | Class 1.0 |
| Energy Measurement | Active Energy & Apparent Energy |
| Energy Direction | Forward, Import & Export |
| Surge Withstand | Up to 10kV |
| Meter Constants | 6400 / 3200 / 1280 imp/kWh |
| IP Rating | IP54 |
| Specification | Details |
|---|---|
| Communication | Optical Port, IEC 62056-21 |
| Optional Communication | BLE / RS232 Micro-USB |
| Multi-Tariff | Up to 8 Rate Registers & 8 Time Zones |
| Load Survey | More than 150 days |
| Historical Billing | 12 Billing Periods |
| Tamper Event Memory | Up to 300 timestamped events |
| Specification | Details |
|---|---|
| Dimensions | Approx. 95 × 130 × 60 mm |
| Weight | Approx. 0.3 kg |
| Enclosure | Sealed Engineering Plastic |
| Operating Temperature | -20°C to +60°C |
| Humidity | Up to 95% non-condensing |
| Standards | IS 13779, IEC 62052-11, IEC 62053-21, IS 15959 |
Detailed description
Product Overview
The Secure Saral Single Phase Net Meter is a compact direct-connected energy meter designed for single-phase 230V/240V electrical systems. It is suitable for applications where accurate electricity consumption measurement and bidirectional energy monitoring are required.
With support for forward, import and export energy measurement, the Secure Saral can be used in applicable rooftop solar and net-metering installations where electricity may flow between the property and the utility grid in both directions.
Bidirectional Energy Measurement
One of the important features of the Secure Saral is its ability to record energy in both directions. During periods when solar generation is insufficient for the connected load, electricity can be imported from the grid. When solar generation exceeds the local demand, surplus electricity can be exported to the grid.
The meter is designed to register these import and export energy flows, making it suitable for applicable single-phase solar energy monitoring and net-metering applications.
Class 1.0 Metering Accuracy
Secure Saral provides Class 1.0 metering accuracy for applicable energy measurement requirements. It can measure active and apparent energy while maintaining records for different energy directions.
This makes the meter suitable for residential electricity monitoring, commercial applications and single-phase rooftop solar systems where accurate energy measurement is required.
Multiple Current Rating Options
The Secure Saral is available with different current configurations, including:
5–30A
10–60A
10–100A
The appropriate current rating should be selected according to the electrical installation and applicable requirements.
Anti-Tamper & Event Recording
The meter includes tamper-event recording capabilities and can retain up to 300 timestamped tamper events. These features are intended to support reliable measurement and event monitoring in utility and energy-management applications.
10kV Surge Withstand
The Secure Saral provides up to 10kV surge withstand capability, helping the meter withstand specified high-voltage surge conditions.
For solar installations, appropriate external protection such as SPD, earthing and lightning protection should still be designed and installed according to the electrical system requirements.
Compact IP54 Design
The Secure Saral features a compact sealed engineering-plastic enclosure measuring approximately 95 × 130 × 60 mm and weighing around 0.3 kg.
Its IP54 protection and operating temperature range of approximately -20°C to +60°C make it suitable for appropriate indoor and protected outdoor electrical installation environments.
Data Storage & Multi-Tariff Support
The meter supports up to 8 rate registers and 8 time zones, which can be useful for applications requiring multiple tariff periods.
It can also retain more than 150 days of load-survey data and up to 12 billing periods of historical billing information, depending on configuration and application.
Communication
For meter data access, Secure Saral provides an IEC 62056-21 optical communication port. Depending on the selected configuration, optional communication interfaces may include BLE or RS232 Micro-USB.
Applications in Bangladesh
The Secure Saral Single Phase Net Meter can be considered for:
Single-phase rooftop solar systems
Solar net-metering installations
Residential electricity monitoring
Commercial electricity monitoring
Import/export energy measurement
Solar generation and export monitoring
Energy consumption monitoring
Utility and revenue-protection applications
230V/240V single-phase electrical systems
For solar net-metering projects, the exact meter specification and approval requirements should be confirmed with the relevant electricity distribution authority before installation.
Why Choose Secure Saral Single Phase Net Meter?
The Secure Saral combines bidirectional energy measurement, Class 1.0 accuracy, multiple current-rating options, tamper-event recording, communication capability and compact IP54 construction. These features make it a practical option for applicable single-phase energy-monitoring and solar net-metering applications.
Why Buy from MuthoBD.com?
Original and genuine products
Competitive price in Bangladesh
Reliable customer support
Product information and technical guidance
Nationwide delivery options
After-sales support
SEO-Friendly Ending
If you are looking for a Secure Saral Single Phase Net Meter in Bangladesh, this meter offers bidirectional import and export energy measurement, Class 1.0 accuracy, multiple current ratings and useful data-recording features for applicable residential, commercial and rooftop solar applications. Check the latest Secure Saral Net Meter price in Bangladesh from MuthoBD.com and select the appropriate configuration according to your electrical and solar system requirements.
- The Secure Saral is a direct-connected single-phase 2-wire energy meter designed for 230V/240V systems. It supports import and export energy measurement.
