Sorotec REVO VM II PRO 6KW Solar Inverter
In Stock
Key Features
6000W rated output power with 12000VA surge capacity.
48VDC battery system.
Pure sine wave AC output.
MPPT solar charging with a 60–450VDC operating range.
Supports solar array input up to 5500W according to the supplied series datasheet.
Two-year warranty as specified in the product details.
WhatsApp+880 1805 026888
Payment Option:
Payment options will be updated soon.
Product URL: https://www.muthobd.com/product/sorotec-revo-vm-ii-pro-6-kw-solar-inverter
Specification
| Specification | Details |
|---|---|
| Brand | Sorotec |
| Model | REVO VM II PRO 6KW |
| Rated Power | 6000W / 6000VA |
| System Voltage | 48VDC |
| Maximum PV Array Power | 5500W (series datasheet) |
| Waveform | Pure Sine Wave |
| Solar Charge Controller | MPPT |
| Country of Origin | China |
| Warranty | 2 Years |
| Product Category | Hybrid Solar Inverter |
| Specification | Details |
|---|---|
| AC Input Voltage | 230VAC (220VAC / 240VAC) |
| Selectable Voltage Range | 170–280VAC (Personal Computers); 90–280VAC (Home Appliances) |
| Frequency Range | 50Hz / 60Hz, Auto-sensing |
| Specification | Details |
|---|---|
| Rated Output Power | 6000W |
| Surge Power | 12000VA |
| Output Voltage Regulation (Battery Mode) | 230VAC ± 5% |
| Peak Efficiency | 93% |
| Transfer Time | 10ms (Personal Computers); 20ms (Home Appliances) |
| Output Waveform | Pure Sine Wave |
| Specification | Details |
|---|---|
| Maximum PV Array Open-Circuit Voltage | 500VDC |
| Maximum PV Array Power | 5500W |
| MPPT Operating Voltage Range | 60–450VDC |
| Maximum Solar Charging Current | 120A |
| Maximum AC Charging Current | 80A |
| Maximum Combined Charging Current | 120A |
| Specification | Details |
|---|---|
| Rated Battery Voltage | 48VDC |
| Floating Charge Voltage | 54VDC |
| Overcharge Protection Voltage | 63VDC |
| Specification | Details |
|---|---|
| Dimensions (D × W × H) | 400 × 300 × 115 mm (series datasheet) |
| Net Weight | 9 kg (series datasheet) |
| Operating Temperature | -10°C to 50°C |
| Relative Humidity | 5%–95%, non-condensing |
| Communication Interface | USB / RS232; optional CAN / RS485 |
| Safety Standard | EN/IEC 62109-1, EN/IEC 62109-2 |
Detailed description
Sorotec REVO VM II PRO 6KW Solar Inverter
The Sorotec REVO VM II PRO 6KW Solar Inverter is designed for solar energy and battery backup systems that require high-capacity AC power. With a rated output of 6000W, a 48VDC battery system and pure sine wave output, it is suitable for consideration in compatible residential and commercial solar installations.
The supplied REVO VM II PRO series datasheet lists a surge capacity of 12000VA and MPPT solar charging. Customers should confirm the exact model's specifications and system compatibility before purchasing.
6000W Rated Output with Pure Sine Wave
This Sorotec inverter has a rated output of 6000W/6000VA and a listed surge rating of 12000VA. Its pure sine wave output is designed for compatible appliances and electrical equipment requiring AC power.
The series datasheet specifies 230VAC output regulation with a tolerance of ±5% in battery mode. Listed AC voltage options include 220VAC, 230VAC and 240VAC. Actual load suitability depends on appliance power consumption, starting current and the inverter's operating conditions.
MPPT Solar Charging
The supplied series datasheet lists a maximum PV array power of 5500W, a maximum PV open-circuit voltage of 500VDC and an MPPT operating voltage range of 60–450VDC. The listed maximum solar charging current is 120A.
Solar panels must be arranged within the inverter's permitted voltage and current limits. Check the panel specifications, series-string voltage and total array power before installation. The datasheet also lists a maximum AC charging current of 80A and a maximum combined charging current of 120A.
48V Battery System
The REVO VM II PRO 6KW uses a 48VDC battery system. The supplied series datasheet lists a floating charge voltage of 54VDC and an overcharge protection voltage of 63VDC for the 48V model group.
Confirm the supported battery chemistry, charging settings and battery capacity before connecting a battery bank. For lithium batteries, verify compatibility with the battery management system and the inverter's charging profile.
AC Input and Backup Performance
The series datasheet lists a nominal AC input voltage of 230VAC, with 220VAC and 240VAC options, and automatic 50Hz/60Hz frequency sensing. The selectable input range is 170–280VAC for personal computers and 90–280VAC for home appliances.
The stated transfer time is 10ms for personal computers and 20ms for home appliances. These are manufacturer-listed figures and do not guarantee uninterrupted operation for every connected device.
Buy Sorotec REVO VM II PRO 6KW from Muthobd.com
Muthobd.com offers solar products and power solutions for customers in Bangladesh. The Sorotec REVO VM II PRO 6KW is an option for customers planning a compatible 48V solar and battery backup system.
The product details specify a two-year warranty. Before ordering, confirm the exact model, PV input limits, battery compatibility, included accessories and warranty terms with the supplier. Professional installation is recommended for safe system design and reliable operation.
- The model is Sorotec REVO VM II PRO 6KW.
