Sorotec REVO VM IV PRO 4KW Solar Inverter
In Stock
Key Features
4000W rated power with 8000VA surge capacity.
24VDC battery system compatible with lithium and lead-acid batteries.
MPPT solar charging with a 60–450VDC operating range.
Supports up to 5000W maximum PV array power.
5-inch colour LCD and optional Wi-Fi/Bluetooth communication.
Two-year warranty as specified in the product details.
WhatsApp+880 1805 026888
Payment Option:
Payment options will be updated soon.
Product URL: https://www.muthobd.com/product/sorotec-revo-vm-iv-pro-4-kw-solar-inverter
Specification
| Specification | Details |
|---|---|
| Brand | Sorotec |
| Model | REVO VM IV PRO 4KW |
| Rated Power | 4000W / 4000VA |
| System Voltage | 24VDC |
| Maximum PV Array Power | 5000W |
| Waveform | Pure Sine Wave |
| Solar Charge Controller | MPPT |
| Battery Compatibility | Lithium and Lead-acid |
| Display | 5-inch Colour LCD |
| Country of Origin | China |
| Warranty | 2 Years |
| Product Category | Hybrid Solar Inverter |
| Specification | Details |
|---|---|
| Nominal Voltage | 230VAC |
| Input Voltage Range | 170–280VAC / 90–280VAC |
| Frequency Range | 50Hz / 60Hz |
| Specification | Details |
|---|---|
| Rated Output Power | 4000W |
| Surge Power | 8000VA |
| Output Voltage | 220V / 230V / 240V |
| Output Frequency | 50Hz / 60Hz |
| Output Waveform | Pure Sine Wave |
| Maximum Efficiency | 93% |
| Transfer Time | 10ms typical (narrow range); 20ms typical (wide range) |
| Specification | Details |
|---|---|
| Maximum PV Array Open-Circuit Voltage | 500VDC |
| Maximum PV Array Power | 5000W |
| MPPT Operating Voltage Range | 60–450VDC |
| Maximum Solar Charging Current | 120A (series datasheet) |
| Maximum AC Charging Current | Not individually specified for the 4KW model |
| Maximum Charging Current | 120A (series datasheet) |
| Specification | Details |
|---|---|
| Nominal Battery Voltage | 24VDC |
| Floating Charge Voltage | 27VDC |
| Overcharge Protection Voltage | 31VDC |
| Battery Type | Lithium and Lead-acid |
| Specification | Details |
|---|---|
| Display | 5-inch Colour LCD |
| Standard Communication | RS232, CAN, RS485 |
| Optional Communication | Wi-Fi, Bluetooth |
| Parallel Function | Up to 6 units (series datasheet) |
| Specification | Details |
|---|---|
| Dimensions (D × W × H) | 434 × 311 × 126.5 mm (series datasheet) |
| Net Weight | 9 kg (series datasheet) |
| Operating Temperature | -10°C to 50°C |
| Relative Humidity | 5%–90% RH, non-condensing |
Detailed description
Sorotec REVO VM IV PRO 4KW Solar Inverter
The Sorotec REVO VM IV PRO 4KW Solar Inverter is designed for solar energy and battery backup systems that require dependable AC power. With a rated output of 4000W, a 24VDC battery system and pure sine wave output, it is an option for compatible residential and small commercial solar installations.
The supplied REVO VM IV series datasheet lists an 8000VA surge rating, MPPT solar charging and a 5-inch colour LCD display. Check the exact model specifications before purchasing to ensure compatibility with your solar panels, battery bank and electrical loads.
4000W Output and Pure Sine Wave
This inverter provides a rated output of 4000W/4000VA and a listed surge capacity of 8000VA. Its pure sine wave output is designed for compatible electrical appliances and equipment requiring AC power.
The series datasheet lists output voltage options of 220V, 230V and 240V, with a 50Hz/60Hz output frequency. Maximum efficiency is specified as 93%. Actual performance depends on operating conditions, load and system configuration.
MPPT Solar Charging
The supplied series datasheet specifies a maximum PV array power of 5000W for the 4KW model, a maximum PV open-circuit voltage of 500VDC and an MPPT operating voltage range of 60–450VDC.
When planning a solar installation, ensure that the panel string voltage and current remain within the inverter's limits. Correct solar array sizing helps maintain compatibility and supports reliable operation.
24V Battery Compatibility
The Sorotec REVO VM IV PRO 4KW uses a 24VDC battery system. The series datasheet lists compatibility with lithium and lead-acid batteries, a floating charge voltage of 27VDC and an overcharge protection voltage of 31VDC.
Before connecting a battery, confirm the supported battery chemistry, charging profile and required battery capacity. Lithium battery installations should also be checked for compatibility with the battery management system.
LCD Display and Communication
The REVO VM IV series includes a 5-inch colour LCD display. Standard communication interfaces listed in the datasheet include RS232, CAN and RS485, while Wi-Fi and Bluetooth are optional.
The series datasheet also lists parallel operation for up to six units. Confirm that parallel functionality and any required communication accessories are supported by the exact model and installation configuration.
Buy Sorotec REVO VM IV PRO 4KW from Muthobd.com
Muthobd.com offers solar products and power solutions for customers in Bangladesh. The Sorotec REVO VM IV PRO 4KW is worth considering for a compatible 24V solar and battery backup system.
The product information specifies a two-year warranty. Before ordering, confirm the current price, exact model, included accessories, battery compatibility and warranty terms with the supplier. Professional installation is recommended for safe system design and operation.
- The model is Sorotec REVO VM IV PRO 4KW.
