SUNSHINE 85W 12V Monocrystalline Solar Panel SS-85W-M
In Stock
Key Features
85W Solar Power Output: Suitable for small off-grid solar applications and compatible 12V battery systems.
Monocrystalline Germany Cell Technology: Designed for efficient solar energy conversion.
MBB Solar Cell Design: Supports light absorption and helps reduce power loss.
Low-Light Performance: Designed to generate power under weak sunlight and cloudy conditions.
Durable Construction: Salt mist and ammonia resistance for challenging environments.
25-Year Linear Power Warranty: Long-term power output coverage, subject to the applicable warranty terms.
WhatsApp+880 1805 026888
Payment Option:
Payment options will be updated soon.
Product URL: https://www.muthobd.com/product/sunshine-85-w-12-v-monocrystalline-solar-panel-ss-85-w-m
Specification
| Specification | Value |
|---|---|
| Brand | SUNSHINE |
| Model | SS-85W-M |
| Product Type | Monocrystalline Solar Panel |
| Rated Power Output | 85W |
| Cell Technology | Monocrystalline Germany Cell Technology |
| Panel Design | MBB (Multi-Busbar) |
| System Type | 12V Nominal Battery System |
| Application Class | Class A |
| Power Tolerance | 0 to +5W |
| Linear Power Warranty | 25 Years |
| Specification | Value |
|---|---|
| Maximum Power (Pmax) | 85W |
| Voltage at Maximum Power (Vmp) | 18V |
| Current at Maximum Power (Imp) | 4.72A |
| Open Circuit Voltage (Voc) | 21.06V |
| Short Circuit Current (Isc) | 5.52A |
| Maximum System Voltage | 1000V |
| Maximum Series Fuse Rating | 20A |
| Specification | Value |
|---|---|
| Dimensions | 730 × 575 × 25 mm |
| Cell Type | Monocrystalline |
| Busbar Design | MBB |
| Weight | Not Specified |
| Specification | Value |
|---|---|
| Low-Light Performance | Excellent low-light performance (manufacturer-stated) |
| Salt Mist Resistance | Yes, as stated in supplied specifications |
| Ammonia Resistance | Yes, as stated in supplied specifications |
| PID Protection | PID-free technology (manufacturer-stated) |
| Warranty Type | Linear Power Output Warranty |
| Warranty Period | 25 Years |
Detailed description
SUNSHINE 85W 12V Monocrystalline Solar Panel
The SUNSHINE 85W Germany Cell 12V Mono Solar Panel SS-85W-M is designed for small off-grid solar systems that require a compact and reliable source of renewable electricity. Featuring monocrystalline Germany cell technology and an MBB (Multi-Busbar) design, this solar module is suitable for compatible 12V battery charging applications and other small-scale solar power setups.
With a rated output of 85W, the SUNSHINE solar panel can be considered for applications such as small lighting systems, compact battery charging setups, low-power equipment and remote installations. Actual performance depends on sunlight availability, panel orientation, shading, temperature and the specifications of the connected charge controller and battery.
Monocrystalline Germany Cell Technology
The SUNSHINE SS-85W-M uses monocrystalline solar cells designed to convert sunlight into DC electricity. Its MBB design is intended to improve light absorption and reduce power losses. These features support efficient energy generation within the panel's 85W rated output class.
The manufacturer also states that the panel offers excellent low-light performance. While this can be useful during cloudy conditions or periods of weaker sunlight, actual energy production will vary with irradiance and site conditions.
Electrical Performance for 12V Battery Systems
The panel has a maximum-power voltage (Vmp) of 18V and a maximum-power current (Imp) of 4.72A. Its open-circuit voltage (Voc) is 21.06V, while its short-circuit current (Isc) is 5.52A.
These electrical ratings are important when selecting a compatible solar charge controller. Although the panel is intended for 12V nominal battery systems, the correct controller must be selected according to the battery chemistry, charging voltage and panel specifications. A suitable charge controller helps regulate the power supplied to the battery.
The panel supports a maximum system voltage rating of 1000V and has a maximum series fuse rating of 20A. These ratings should be considered during system design and do not mean that the panel should be connected directly to a battery without appropriate charge regulation.
Designed for Challenging Environments
The supplied product information identifies salt mist and ammonia resistance, making the panel worth considering for installations where these environmental factors are relevant. The manufacturer also describes the module as using PID-free technology to support long-term power stability.
The stated dimensions are 730 × 575 × 25 mm, allowing the panel to be considered for compact installations where mounting space is limited. A suitable mounting structure and secure electrical connections should be used for reliable outdoor operation.
Suitable Applications
The SUNSHINE 85W solar panel may be suitable for:
Small off-grid solar systems
Compatible 12V battery charging setups
Solar lighting and low-power applications
Remote monitoring equipment with compatible power requirements
Small renewable energy projects
The appropriate application depends on the equipment's energy consumption, daily sunlight availability, battery capacity and system design.
25-Year Linear Power Warranty
SUNSHINE specifies a 25-year linear power output warranty for this panel. Buyers should review the applicable warranty documentation to confirm coverage, degradation conditions and claim requirements.
For customers in Bangladesh looking for a compact solar panel for a small off-grid project, the SUNSHINE SS-85W-M offers 85W rated output, monocrystalline cell technology, MBB design and stated environmental resistance features. Explore the SUNSHINE 85W Solar Panel at Muthobd.com for your solar power requirements.
- The SUNSHINE SS-85W-M has a rated maximum power output of 85W.
