What is the Deye SE-F5 PLUS-C battery?

It is a 51.2V LiFePO4 energy storage battery designed for compatible solar and backup power systems.

What is the stated cycle life?

The supplied specifications state 6,000 cycles at 90% depth of discharge (DOD), under specified conditions.

What is the maximum discharge current?

The supplied information lists both 100A and 120A. Confirm the correct rating from the official datasheet.

Does it have an LCD display?

Yes. The supplied specifications state that the LCD displays state of charge (SOC) and fault codes.

Can I monitor the battery through a mobile app?

Yes. Bluetooth app monitoring is listed in the supplied information.

Which communication protocols does it support?

It supports CAN 2.0 and RS485 communication.

Can multiple batteries be connected in parallel?

The supplied information states that up to 32 units can be connected in parallel, subject to manufacturer requirements.

What mounting options are available?

Wall-mounted, floor-mounted and stack-mounted options are listed.

Is it compatible with every solar inverter?

No. Compatibility depends on battery voltage requirements, communication protocols and manufacturer-approved compatibility.

What is the warranty period?

The supplied product details state a 10-year official warranty. Confirm the applicable terms and conditions before purchase.

Deye SE-F5 PLUS-C 51.2V 100Ah 5.12kWh LiFePO4 Lithium Battery

Name: Deye SE-F5 PLUS-C 51.2V 100Ah 5.12kWh LiFePO4 Lithium Battery
Brand: deye
Price: 135000 BDT
Availability: InStock

In Stock

৳ 135,000৳ 145,000

Key Features

5.12kWh Energy Storage: Provides nominal energy storage for compatible solar and backup power systems.
51.2V 100Ah Battery: Designed for compatible 51.2V battery inverter systems.
LiFePO4 Battery Chemistry: Uses lithium iron phosphate battery technology.
6,000 Cycles at 90% DOD: Designed for repeated charging and discharging under specified conditions.
High Discharge Capability: The supplied information lists 100A and 120A maximum discharge current; verify the correct rating.
LCD Display: Shows battery state of charge (SOC) and fault codes.
Bluetooth App Monitoring: Supports battery monitoring through a compatible application.
CAN 2.0 and RS485: Supports communication with compatible inverters and energy management systems.
Expandable up to 32 Units: Supports parallel battery expansion, subject to manufacturer requirements.
Flexible Installation: Supports wall-mounted, floor-mounted and stack-mounted configurations.
10-Year Official Warranty: Warranty coverage as supplied.

WhatsApp Phone Call

+880 1805 026888

Payment Option:

Payment options will be updated soon.

Quantity :

Specification

General Information

Specification	Details
Brand	Deye
Model	SE-F5 PLUS-C
Product Type	LiFePO4 Lithium Battery
Nominal Voltage	51.2V DC
Rated Capacity	100Ah
Nominal Energy	5.12kWh
Cycle Life	6,000 Cycles at 90% DOD
Maximum Discharge Current	100A / 120A — confirm specification
Warranty	10-Year Official Warranty

Display and Communication

Specification	Details
Display	LCD
Display Information	State of Charge (SOC) and Fault Codes
App Monitoring	Bluetooth
Communication Ports	CAN 2.0 / RS485

Installation and Expansion

Specification	Details
Mounting Options	Wall-Mounted / Floor-Mounted / Stack-Mounted
Parallel Connection	Up to 32 Units
Nominal Energy per Battery	5.12kWh

Product Description

Deye SE-F5 PLUS-C 51.2V 100Ah 5.12kWh LiFePO4 Battery

The Deye SE-F5 PLUS-C 51.2V 100Ah 5.12kWh LiFePO4 Battery is an energy storage solution designed for compatible solar power systems, hybrid inverters and battery-based backup installations. With a nominal voltage of 51.2V DC, a rated capacity of 100Ah and nominal energy of 5.12kWh, it offers energy storage for residential and commercial applications requiring a compatible lithium battery system.

5.12kWh Nominal Energy Capacity

The Deye SE-F5 PLUS-C provides 5.12kWh of nominal energy storage. Its 51.2V DC voltage and 100Ah rated capacity make it suitable for compatible battery-based energy storage systems.

Actual usable energy and backup duration depend on permitted depth of discharge, inverter efficiency, connected load and operating conditions. Check inverter compatibility before installation.

LiFePO4 Battery with 6,000-Cycle Life

The supplied specifications state a cycle life of 6,000 cycles at 90% depth of discharge (DOD). This indicates the stated cycle-life performance under the manufacturer's specified testing conditions.

Actual battery lifespan depends on charging and discharging practices, temperature, current levels and installation conditions. Follow the manufacturer's instructions to support reliable long-term operation.

Discharge Current Specification

The supplied product details list both 100A and 120A maximum discharge current. Because these values differ, the correct maximum discharge rating should be confirmed from the official datasheet before purchasing or designing the battery system.

The supported output power depends on battery voltage, permitted discharge current, inverter compatibility and operating conditions. Properly rated cables and protective devices are essential.

LCD Display and Bluetooth App Monitoring

The battery features an LCD display that provides state-of-charge (SOC) information and fault codes. This helps users check battery status and review displayed fault information.

Bluetooth app monitoring provides another way to access supported battery information through a compatible mobile application. Confirm app compatibility and available functions with the manufacturer.

CAN 2.0 and RS485 Communication

The Deye SE-F5 PLUS-C supports CAN 2.0 and RS485 communication interfaces. These interfaces allow communication with compatible inverters and energy management systems, helping coordinate battery operation and monitoring.

Before installation, verify that the selected inverter supports this battery model and its communication protocol.

Expandable Battery Storage up to 32 Units

The supplied specifications state that up to 32 units can be connected in parallel. Parallel expansion can increase total nominal energy storage when the manufacturer's requirements are followed.

For reference, 32 batteries rated at 5.12kWh each represent a theoretical combined nominal capacity of 163.84kWh. Actual usable energy and supported system configuration depend on the manufacturer's limits and the installation design.

A qualified installer should confirm the approved number of batteries, inverter capacity, cabling, protection and communication setup before expanding the system.

Flexible Wall, Floor and Stack Mounting

The supplied information lists three mounting options:

Wall-mounted
Floor-mounted
Stack-mounted

These options provide flexibility for different installation spaces. Follow the official mounting instructions, clearance requirements and electrical safety guidelines.

Applications for Solar and Backup Power

Depending on inverter compatibility and system design, the Deye SE-F5 PLUS-C may be considered for:

Residential solar energy storage
Compatible hybrid inverter systems
Home backup power installations
Commercial battery storage
Expandable solar energy storage projects

Actual backup time depends on usable battery capacity, connected load and system efficiency. Battery sizing should account for energy consumption, required backup duration and permitted discharge limits.

10-Year Official Warranty

The supplied product information states a 10-year official warranty. Confirm warranty terms, eligibility requirements, installation conditions and service arrangements with the authorized seller before purchase.

The Deye SE-F5 PLUS-C combines 51.2V, 100Ah specifications, 5.12kWh nominal energy, a stated 6,000-cycle life at 90% DOD, smart monitoring and expandable installation options. Confirm the maximum discharge current and complete official datasheet before finalizing a system.
