GoodWe GW10K-SDT-30 10KW Three Phase On-Grid Solar Inverter

GoodWe is one of the world's leading manufacturers of solar inverters, trusted for delivering reliable, efficient, and intelligent energy solutions for residential, commercial, and industrial photovoltaic systems. The GoodWe GW10K-SDT-30 10KW Three Phase On-Grid Solar Inverter is designed to maximize solar energy production while ensuring safe, stable, and long-lasting operation.

Built with advanced power conversion technology, the GW10K-SDT-30 delivers a maximum efficiency of 98.6%, allowing more solar energy to be converted into usable electricity. Its dual MPPT architecture provides greater flexibility for solar array design and improves energy harvesting when panels are installed on different roof orientations or operate under partial shading.

Designed for Bangladesh's growing demand for reliable renewable energy solutions, this inverter combines high efficiency, intelligent monitoring, comprehensive safety protection, and durable construction, making it an excellent choice for residential, commercial, and industrial grid-connected solar installations.

Key Features

Exceptional Energy Conversion

With a maximum efficiency of 98.6% and European efficiency of 98.0%, the GoodWe GW10K-SDT-30 minimizes conversion losses and helps maximize electricity production throughout the day.

Dual MPPT Technology

The inverter features two independent Maximum Power Point Trackers (MPPTs), allowing multiple solar panel strings to operate at their optimum performance. This improves energy generation when panels face different directions or experience uneven sunlight.

Intelligent Remote Monitoring

Users can monitor system performance in real time through the GoodWe SEMS monitoring platform using optional Wi-Fi, LAN, or GPRS communication. The system provides valuable information about power generation, operating status, and system health from anywhere.

Advanced Safety Protection

The GoodWe GW10K-SDT-30 integrates multiple protection mechanisms for dependable operation, including:

• Arc Fault Circuit Interrupter (AFCI)

• DC reverse polarity protection

• AC overcurrent protection

• AC short circuit protection

• Type II DC & AC surge protection

• Residual current monitoring

• Insulation resistance detection

These features help improve electrical safety while protecting both the inverter and the connected solar system.

Quiet & Durable Operation

Natural convection cooling eliminates the need for internal cooling fans, reducing operating noise and minimizing maintenance requirements while extending product lifespan.

Technical Highlights

The GoodWe GW10K-SDT-30 combines advanced engineering with intelligent energy management features.

Key technical highlights include:

• 10KW rated AC output power

• 13KW maximum DC input power

• Maximum efficiency of 98.6%

• Dual MPPT design

• MPPT operating voltage range of 180V–850V

• Maximum DC input voltage of 1000V

• Transformerless topology

• Integrated AFCI protection

• Built-in Type II surge protection (DC & AC)

• IP65 weather-resistant enclosure

• Natural convection cooling

• LCD display with LED indicators

• Optional Wi-Fi, LAN, and GPRS communication

• RS485 communication interface

• 5-year standard warranty with extension options

Applications

The GoodWe GW10K-SDT-30 is suitable for a wide variety of three-phase solar power installations, including:

• Residential rooftop solar systems

• Commercial office buildings

• Shopping malls

• Educational institutions

• Hospitals and healthcare facilities

• Hotels and resorts

• Industrial buildings

• Factories and warehouses

• Agricultural solar projects

• Commercial photovoltaic systems

Its flexible design makes it suitable for both new installations and system upgrades.

Why Choose This Product

The GoodWe GW10K-SDT-30 is designed to provide outstanding efficiency, intelligent monitoring, and dependable long-term performance. Its dual MPPT technology increases energy production while the wide operating voltage range offers greater flexibility when designing solar systems.

Integrated AFCI protection and Type II surge protection enhance electrical safety, while the IP65-rated enclosure ensures reliable outdoor operation in challenging environments. The fanless cooling system reduces maintenance and provides quiet operation, making it suitable for residential and commercial installations.

Whether you are installing a solar system for a home, office, factory, or commercial building, the GoodWe GW10K-SDT-30 offers an ideal balance of efficiency, reliability, and advanced technology.
