LVTOPSUN LVTS-128280-E 12.8V 280Ah LiFePO₄ Lithium Battery 3.584kWh
In Stock
Key Features
280Ah High-Capacity Battery: Provides substantial energy storage for compatible solar power systems.
3.584kWh Energy Storage: Delivers 12.8V nominal voltage and 280Ah capacity.
LiFePO₄ Battery Technology: Uses lithium iron phosphate chemistry for rechargeable energy storage.
6,000+ Life Cycles: Rated for 6,000+ cycles at 80% depth of discharge (DoD).
Smart Integrated BMS: Helps manage battery operation and supports the listed protection functions.
High Discharge Capability: Supports 200A rated discharge current and 400A peak discharge current for short durations.
100A Rated Charging Current: Supports charging within the specified current rating.
Greater Than 95% Efficiency: Features a stated battery efficiency of over 95%.
Wall-Mount Installation: Designed for wall-mounted installation.
6-Year Warranty: Includes a stated six-year warranty.
WhatsApp+880 1805 026888
Payment Option:
Payment options will be updated soon.
Product URL: https://www.muthobd.com/product/lvtopsun-lvts-128280-e-12-8-v-280-ah-li-fe-po-lithium-battery-3-584k-wh
Specification
| Specification | Details |
|---|---|
| Brand | LVTOPSUN |
| Product Name | Residential Photovoltaic Energy Storage Lithium-Ion Battery |
| Model | LVTS-128280-E |
| Product Type | Lithium Battery |
| Battery Chemistry | LiFePO₄ (Lithium Iron Phosphate) |
| Nominal Voltage | 12.8V DC |
| Battery Capacity | 280Ah |
| Energy Storage Capacity | 3.584kWh |
| Battery Efficiency | Greater than 95% |
| Installation Type | Wall Mount |
| Warranty | 6 Years |
| Specification | Details |
|---|---|
| Rated Charge Current | 100A |
| Rated Discharge Current | 200A |
| Peak Discharge Current | 400A (Short Duration) |
| Battery Life Cycle | 6,000+ cycles at 80% DoD |
| Specification | Details |
|---|---|
| Battery Management System | Smart Integrated BMS |
| Protection Features | Overcharge, Over-discharge, Overcurrent, Short Circuit, Temperature Protection |
| Specification | Details |
|---|---|
| Storage Temperature | -20°C to +45°C |
| Operating Temperature | -20°C to +60°C |
Detailed description
LVTOPSUN LVTS-128280-E 12.8V 280Ah LiFePO₄ Lithium Battery
The LVTOPSUN LVTS-128280-E Residential Photovoltaic Energy Storage Battery is designed for compatible residential solar energy storage and backup power applications. It combines a 12.8V nominal voltage, 280Ah capacity, and 3.584kWh energy storage in a lithium iron phosphate battery system with a smart integrated battery management system (BMS).
3.584kWh Energy Storage Capacity
The LVTOPSUN LVTS-128280-E provides a nominal energy capacity of 3.584kWh. With a 12.8V nominal voltage and 280Ah battery capacity, it is designed to store electrical energy for compatible low-voltage solar and backup power systems.
Actual usable energy and backup duration depend on the connected load, discharge limits, system efficiency, and operating conditions.
LiFePO₄ Battery Technology
This battery uses lithium iron phosphate (LiFePO₄) chemistry. It is designed for rechargeable energy storage in residential photovoltaic systems and compatible backup applications.
The supplied specifications list a battery efficiency of greater than 95%. Actual system efficiency can vary depending on charging and discharging conditions, temperature, and connected equipment.
6,000+ Battery Life Cycles
The LVTOPSUN LVTS-128280-E is rated for 6,000+ cycles at 80% depth of discharge (DoD). This rating describes the stated cycle-life performance under the manufacturer's specified test conditions.
Actual battery lifespan depends on operating temperature, charging practices, discharge conditions, and usage patterns.
Smart Integrated Battery Management System
The battery includes a smart integrated BMS with the following listed protection functions:
Overcharge protection
Over-discharge protection
Overcurrent protection
Short-circuit protection
Temperature protection
These protection functions help manage battery operation within supported limits. The complete system should still use compatible charging equipment, appropriate wiring, and correctly rated electrical protection devices.
Charging and Discharging Performance
The battery supports a rated charging current of 100A and a rated discharging current of 200A. It also lists a peak discharge current of 400A for short durations.
These ratings are important when selecting an inverter, charger, cables, and protective devices. The connected equipment must comply with the battery's voltage and current limits. Peak discharge current should only be used within the manufacturer's permitted duration and operating conditions.
Wall-Mount Installation
The LVTOPSUN LVTS-128280-E is designed for wall-mounted installation. Before installation, ensure the mounting surface, brackets, electrical connections, and surrounding environment meet the manufacturer's requirements.
Operating Temperature and Storage
The supplied specifications list an operating temperature range of -20°C to +60°C and a storage temperature range of -20°C to +45°C.
Following the manufacturer's temperature and storage recommendations helps support safe operation and battery performance.
Suitable Applications
Depending on electrical compatibility, this battery may be suitable for:
Residential photovoltaic energy storage
Compatible 12.8V DC energy systems
Solar backup power installations
Selected low-voltage inverter systems
Backup power for compatible electrical equipment
Before purchasing, confirm compatibility with your inverter or charge controller, particularly the charging voltage, maximum charging current, discharge current, and communication requirements.
Six-Year Warranty
The supplied product information lists a 6-year warranty. Buyers should confirm the applicable warranty terms, coverage conditions, and service arrangements before purchase.
Buy LVTOPSUN LVTS-128280-E from MuthoBD.com
The LVTOPSUN LVTS-128280-E combines 3.584kWh energy storage, LiFePO₄ battery technology, a smart integrated BMS, and a stated cycle life of 6,000+ cycles at 80% DoD. It is designed for compatible residential photovoltaic energy storage applications.
Explore the LVTOPSUN LVTS-128280-E 12.8V 280Ah Lithium Battery at MuthoBD.com for your solar energy storage requirements.
- The model number is LVTS-128280-E.
